| Case Specification |
| Dimensions |
463 x 220 x 486 mm (DWH) |
| Form Factor |
Mid Tower |
| Materials |
Steel + Plastic |
| Mainboard Support |
ATX, M-ATX, ITX |
| Front Access & Controls |
Power, LED Control Button, 2 x USB3.0, HD-AUDIO |
| Side Panel |
4 mm Tempered Glass Side Panel |
|
| Expansion & Drive Bays |
| Expansion Slots |
7 |
| 5.25″ |
1 |
| 3.5″ /2.5″ |
3/2 |
| 2.5″ |
3 |
|
| Fan |
| Front |
3 x 120 mm / 2 x 140 mm |
| Top |
3 x 120 mm / 2 x 140 mm (w/o ODD and w/o ODD bracket)2 x 120 mm / 2 x 140 mm (w/o ODD but with ODD bracket)2 x 120 mm / 1 x 140 mm (When ODD is installed) |
| Power Supply Shroud |
2 x 120 mm |
| Rear |
1 x 120 mm |
| Pre-installed Fans |
3 x 120 mm fans in front1 x 120 mm fan (Reverse Fan) on PSU shroud& 1 x 120 mm fan in rear |
|
| Radiator Support |
| Front |
120/240/280/360 mm (= 55 mm thickness when fans are installed outside of front panel)(= 30 mm thickness when fans are installed inside of front panel)[Max Radiator Length = 405 mm] |
| Top |
240/280/360 mm (w/o ODD and w/o ODD bracket)240/280 mm (w/o ODD but with ODD bracket)120 mm(When ODD is installed)[Max Radiator Length = 405 mm] |
| Rear |
120 mm |
|
| Clearance |
| Max GPU Length |
= 405 mm |
| Max CPU Cooler Height |
= 175 mm |
| Max PSU Length |
= 205 mm |
|
| Miscellaneous |
| Dust Filter |
Front / Top / Bottom / Right Hand Side |
| Net Weight |
7.55KG |
| Gross Weight |
8.7KG |
|
